Sunrise

Senseair Sunrise is our most accurate and power efficient sensor. It complies with several modern standards including Addendum ab to ANSI/ASHRAE Standard 62.1-2022.

Defining attributes

Compliant with ANSI/ASHRAE Standard 62.1-2022 Addendum ab
Compliant with RESET grade A
Compliant with WELL Building Standard® (WELL v2™)
Optical solid state
Ultra low power consumption
High precision
Robust
Mass production
Self-correcting

Sunrise is a new generation of NDIR sensor with Optical Solid State design. Electronics with no moving parts makes this sensor robust and resistant to vibrations. Any
application with a tough environment or in environments with explosion risk is benefited by the solid state design.

It is the first NDIR sensor with LED technology that truly saves power while maintaining a high precision.

The ultra low power consumption makes Sunrise optimal for battery and wireless applications.

Thanks to the built-in self-correcting algorithm you can mount and forget your sensor for the next 15 years and it will still be accurate.

Article number	006-0-0008
Operating principle	Non-dispersive infrared (NDIR)
Measured gas	CO₂
Measurement range	0–10 000ppm
Accuracy	±30 ppm ±3 % of reading¹
Operating range RH	<85 % RH
Operation range °C	<50 °C
Warm-up time	0 sec
Response time	30s
Power supply	3.05 - 5.5 V
Peak current	125 mA
Average current	1-34μA
Communication	I2C, UART
Outputs	Digital
Compliance	ANSI/ASHRAE Standard 62.1-2022, RESET Standard Grade A, WELL Building Standard® (WELL v2™)
Maintenance	Maintenance free
Life expectancy	>15 years
Dimensions	33.5 x 19.7 x 11.5 mm (L x W x H)
Weight	5 g
Storage conditions	-40 – 70°C

±75ppm Accuracy at 1500–2500ppm (ANSI/ASHRAE compliance)

Disclaimer : Please refer to product specification for the complete technical details.

Article number	Product	Description
006-0-0008	Sunrise	NDIR sensor with Optical Solid State design.
006-0-0007	Sunrise	NDIR sensor with Optical Solid State design.
006-0-0002	Sunrise	NDIR sensor with Optical Solid State design (No longer available).
